5 Must-know Cross Validation Techniques Explained Visually

A 2-min visual guide to popular cross validation techniques.

Dec 12, 2023

Tuning and validating machine learning models on a single validation set can be misleading and sometimes yield overly optimistic results.

This can occur due to a lucky random split of data, which results in a model that performs exceptionally well on the validation set but poorly on new, unseen data.

That is why we often use cross validation instead of simple single-set validation.

Cross validation involves repeatedly partitioning the available data into subsets, training the model on a few subsets, and validating on the remaining subsets.

The main advantage of cross validation is that it provides a more robust and unbiased estimate of model performance compared to the traditional validation method.

Below are five of the most commonly used and must-know cross validation techniques.

Leave-One-Out Cross Validation
- Leave one data point for validation.
- Train the model on the remaining data points.
- Repeat for all points.
- Of course, as you may have guessed, this is practically infeasible when you have many data points. This is because number of models is equal to number of data points.
- We can extend this to Leave-p-Out Cross Validation, where, in each iteration, p observations are reserved for validation, and the rest are used for training.
K-Fold Cross Validation
- Split data into k equally-sized subsets.
- Select one subset for validation.
- Train the model on the remaining subsets.
- Repeat for all subsets.
Rolling Cross Validation
- Mostly used for data with temporal structure.
- Data splitting respects the temporal order, using a fixed-size training window.
- The model is evaluated on the subsequent window.
Blocked Cross Validation
- Another common technique for time-series data.
- In contrast to rolling cross validation, the slice of data is intentionally kept short if the variance does not change appreciably from one window to the next.
- This also saves computation over rolling cross validation.
Stratified Cross Validation
- The above-discussed techniques may not work for imbalanced datasets. Stratified cross validation is mainly used for preserving the class distribution.
- The partitioning ensures that the class distribution is preserved.
